Rated resistance range: |
47...4
700 000 Ohm |
-
- Tolerance on rated resistance :
for
resistance up to 220 K Ohm
for resistance over 220
K Ohm
|
+/-20%
+/-30% |
| -
Power (at a temperature of + 70°С) |
0,125
wt |
| -
Resistance law А ( linear ) |
|
| -
TCR
from 47 Ohm to 4 700 000 Ohm
from 10 Ohm to
47 Ohm |
+0,0015 1/°С
+/-0,00025 1/°С |
| -
Noise level |
5...20
mkV/V |
| -
Total mechanical rotation |
260°С |
| -
Quantity of cycles of operation |
no
more than 500 |
|
|
| -
Operating time to first failure |
15
000 hours |
| -
Mass |
no
more than 2 grm |
