SPECIFICATIONS
ROTATION ANGLE
ROTATION TORQUE
SHAFT STOP STRENGTH
RATED WATTAGE
RATED VOLATAGE
SWITCH CIRCUIT
SWITCH RATING
SWITCH WORKING ANGLE
230°±5°
20~200gf cm
more than 2 kgf cm/min
linear taper(B) Other taper
0.08W 0.04W
150V 100V
S.P.S.T
12VDC,0.5A
30°±10°
