| ELECTRICAL SPECIFICATION |
|
| TOTAL RESISTANCE&TOLERANCE |
5K-2M±20%(MORE THAN 1M±30%) |
| |
|
15mm
|
20mm
|
30mm
|
45mm
|
60mm
|
|
RATED WATTAGE
|
B
|
SINGLE
|
0.05
|
0.1
|
0.2
|
0.25
|
0.2
|
|
DUAL
|
0.025
|
0.05
|
0.1
|
0.125
|
0.2
|
|
EXCEPT B
|
SINGLE
|
0.025
|
0.1
|
0.1
|
0.125
|
0.1
|
|
DUAL
|
0.012
|
0.025
|
0.05
|
0.06
|
0.1
|
|
RATED VOLTAGE
|
B
|
100
|
200
|
200
|
200
|
200
|
|
EXCEPT B
|
50
|
150
|
150
|
150
|
150
|
|
| RESIDUAL RESISTANCE............................................
|
BETWEEN TERMINAL |
|
|
| INSULATION RESISTANCE ......................................... |
MORE THAN 100 M AT 250 VDC |
| WITHSTAND VOLTAGE ................................................. |
FOR 1MINUTE OR MORE AT 100VDC |
| TRACKING ERROR ....................................................... |
-40~0dB<= 3dB |
| |
|
| MECHANICAL SPECIFICATION |
|
| |
|
| LEVER STOR STRENGTH ........................................... |
MORE THAN 50kgf.cm/min |
| OPERATING TORQUE FORCE ................................... |
20-200gf.cm |
| SHAFT LEVER STRENGTH ......................................... |
PULLING PUSHING MORE THAN 3kg |
| SLIDING
LIFE ................................................................. |
MORE THAN 15000 CYCLES |
