RATED WATTAGE
RATED VOLTAGE
ROTARY NOISE
INSULATION RESISTANCE
WITHSTAND VOLTAGE
|
Linear taper(B)Other taper
0.1W 0.05W
100VAC 50VAC
Less than 47mV
More than 10MΩ at 250V
1 minute at AC 250V
|
ROTATION ANGLE
ROTATION TORQUE
SHAFT STOP STRENGTH
LIFE TEST |
250°±5°
20~200 gf.cm
1kgf.cm MAX
15,000 |
|
