Specifications
| - Rated
resistance range: |
1 000...1
000 000 Ohm |
- Tolerance
on rated resistance :
for resistance
up to 220 K Ohm
for resistance
over 220 K Ohm |
+/-20%
+/-30% |
- Resistance
behaviour :
linear type A, rated
power
non-linear type B,
rated power |
0,05 wt
0,025wt |
- TCR
up to 100 K Ohm
over 100
K Ohm |
+/-0,001 1/°С
+/-0,002 1/°С |
| -Quantity
of cycles of operation |
no more
than 10 000 |
| - Operating
time to first failure |
15 000 hours |
| - Mass |
no more
than 2,8 grm |
Operating conditions
Mechaincal
influence
-Sinusoidal
vibration
frequency range
аmplitude of acceleration |
1-200 Hz
49 m/sq sec |
| -
Multiple-operation impacts with acceleration |
342
m/sq sec |
Climatic influence:
| -
Temperature range |
from
-45 to +70°С |
| -
Relative air humidity (at a temperature of
+25°С) |
98% |
|
|
| |
|
